Overview#
The Cummins C55 D5 is a 44 kW / 55 kVA standby (40 kW / 50 kVA prime) diesel generator set from Cummins' international model range, rated at 50 Hz.
The C55D5L variant of the C55 D5 uses the Cummins 4BTAA3.3-G13 engine, with the UCI224C as its standard alternator and the PS0600 as its standard controller.
Technical Specifications#
Power Ratings (50 Hz)
| Rating | kW | kVA |
|---|---|---|
| Standby (ESP) | 44 | 55 |
| Prime (PRP) | 40 | 50 |
Engine: Cummins 4BTAA3.3-G13
Standard alternator: UCI224C
Standard controller: PS0600
Operating Frequency The C55 D5 is a 50 Hz model from Cummins' international model range.
Our Service Experience#
Cummins 50 Hz diesel sets in the 44-66 kVA range are frequently encountered in international import applications, overseas facilities, and marine or offshore installations. Diesel engines in this class require careful attention to wet-stacking when the unit operates at light load or no-load for extended periods. We recommend exercising these units under load to maintain combustion temperatures adequate for clean operation.
For C55 D5 units brought to the United States for domestic use — typically through equipment relocation from international projects — we always verify the generator's original 50 Hz configuration before attempting commissioning. Running a 50 Hz generator at 60 Hz without reconfiguration causes overspeed, overvoltage, and potential engine damage.
Frequently Asked Questions#
Is the C55 D5 available for North American installations? The D5 series is Cummins' international 50 Hz export range. For North American 60 Hz standby in this power range, consult your Cummins distributor for the appropriate D6 model. Attempting to use a 50 Hz C55 D5 on a 60 Hz grid is not supported and will cause equipment damage.
What engine does the C55 D5 use? The C55D5L variant of the C55 D5 uses the Cummins 4BTAA3.3-G13 engine.
What voltage configurations does the C55 D5 support? Confirm available voltage options with your Cummins distributor for the specific regional variant.
How do I identify which Cummins 50 Hz model I have? Check the generator nameplate on the enclosure and the engine data plate. The nameplate will list the full Cummins model number, serial number, rated output in kVA, rated speed in rpm, and rated frequency in Hz. With the serial number, any Cummins distributor can pull the full configuration records.
FAQ#
What is the standby rating of the Cummins C55 D5?#
The C55 D5 is rated for 44 kW / 55 kVA standby output at 50 Hz.
What engine does the Cummins C55 D5 use?#
The C55D5L variant of the C55 D5 uses the Cummins 4BTAA3.3-G13 engine, as listed on Cummins' international 50 Hz rating card.
Can the Cummins C55 D5 be paralleled with other generators?#
Paralleling capability depends on the control system fitted to the specific installation. The standard controller listed for the C55 D5 is the PS0600. For multi-unit paralleling requirements, consult your Cummins distributor for available control options.
What fuel type does the Cummins C55 D5 use?#
The C55 D5 runs on diesel fuel. Confirm fuel specifications with Cummins or your distributor for the specific regional variant.
What voltage configurations does the C55 D5 support?#
Voltage options depend on the alternator specified for the specific regional variant; confirm them with your Cummins distributor.
