Blue Star Power Systems · Volvo Penta Diesel Standby

Blue Star VD230-01

230 kW standby · Diesel · Liquid-cooled

230 kW Tier 3 diesel standby generator from Blue Star Power Systems. Volvo Penta TAD851GE 7.7L inline-six with DSE DCP7310 controller, 208-600V output.

Blue Star Power Systems Blue Star VD230-01 generator — specifications and details
Standby power
230 kW
Voltage options
120/240V, 120/208V, 277/480V, 347/600V
Frequency / Phase
60 Hz · 1/3-phase
Engine
Volvo Penta TAD851GE · 7.7L
EPA / Emissions
Tier 3
Alternator
Stamford UCDI274J1
CommercialHealthcareHospitalityGovernmentlight-industrialdata-center-edge
Configure & QuoteDownload spec sheet

Overview#

The Blue Star VD230-01 is a 230-kilowatt EPA Tier 3 diesel standby generator built around the Volvo Penta TAD851GE inline-six. It sits in the mid-range of Blue Star's Volvo Penta diesel lineup — between the 200 kW class (JD200-01) and the 250 kW VD250-03. This is a current-production active model.

Blue Star Power Systems, Inc. is a Minnesota-based generator-set integrator acquired by DEUTZ AG in August 2024. The VD230-01 represents the updated component platform: DSE DCP7310 controller and Stamford UCDI alternator, replacing the Basler DGC-2020 and Marathon alternators found on earlier Blue Star models.

The Volvo Penta TAD851GE platform#

The TAD851GE is a 7.7-liter inline-six from Volvo Penta's industrial diesel family. It shares bore and stroke dimensions with the smaller TAD572VE (5.13L I-4) and the larger TAD1373VE (12.8L I-6), giving Blue Star a consistent Volvo Penta engine family across the 125-700 kW range.

  • 7.7L inline-six — moderate displacement for the 200-250 kW class, favoring longevity over peak power density
  • Turbocharged with charge-air cooling for tight transient response under step-load conditions
  • Tier 3 certified for stationary emergency standby — no aftertreatment required, which simplifies maintenance versus Tier 4 Final units
  • Electronic unit injection with Volvo Penta EMS for precise fuel metering and diagnostics via CAN bus

Variant selection guide#

The VD230-01 occupies a unique kW point in Blue Star's catalog. Nearby options:

  • VD250-03 (250 kW, Volvo Penta) — same TAD engine family at a higher rating, 20 kW more standby capacity for slightly higher fuel consumption. Choose the VD250-03 if your load study shows peak demand between 230-250 kW.
  • JD200-01 (200 kW, John Deere) — different engine OEM at a lower kW point. John Deere's agricultural service network may offer faster parts access in rural NorCal locations.
  • PD200-01 (200 kW, Perkins) — Perkins-powered alternative at the lower kW boundary. Perkins parts availability through Caterpillar's dealer channel.

For sites requiring Tier 4 Final emissions (California new installations, non-emergency prime), the VD200-04FT4 or VD250-04FT4 are the closest Tier 4 equivalents.

When to spec the VD230-01#

  • 180-230 kW continuous emergency standby loads on diesel fuel
  • Mid-size commercial facilities: full-service hotels, large retail, municipal buildings, school campuses
  • Sites where Tier 3 is permitted (most US jurisdictions for stationary emergency standby)
  • Buyers who prefer Volvo Penta's industrial service channel over John Deere or Perkins
  • Applications requiring 120/240V single-phase output alongside three-phase (the VD230-01 supports both)

Our service experience#

The Volvo Penta TAD851GE is well-supported in Northern California through Volvo Penta's industrial dealer channel. The updated DSE DCP7310 controller on this model is a departure from the Basler DGC-2020 used on earlier Blue Star units — DSE controllers are widely used across the industry and have strong third-party support for programming and monitoring. Stamford alternators are equally well-known, with parts available through Cummins Generator Technologies. As with all Blue Star units in our market, we recommend customers pre-stage primary service items (filters, belts) on-site rather than relying on next-day local availability from a Blue Star dealer.#

Engineering specifications

Physical

Length
120 in
Width
66 in
Height
72 in
Dry weight
5,125 lb

Acoustic

Sound @ 7m, full load
88 dBA
Enclosure
Open

Fuel system & runtime

Fuel use @ full load
17.9 GPH
Fuel use @ 75% load
14.1 GPH
Fuel use @ 50% load
10.3 GPH

Thermal & ventilation

Heat to coolant
371,940 BTU/hr
Heat radiated
290,400 BTU/hr
Exhaust flow
1,926 CFM
Exhaust temp
824 °F
Combustion air
831 CFM

Documents & downloads

Spec sheets & manuals

Ready to order this model?

Configure your Blue Star VD230-01

Lock the enclosure, fuel system, transfer switch, and add-ons — we'll confirm pricing, availability, and lead time within one business day. Prefer a free-form quote? That option is still here.

Configure & Quote →Just request a quoteDownload datasheet

Estimate runtime for the Blue Star VD230-01

Adjust load percent and tank size to estimate runtime. Pre-filled with this model's spec where available.

Estimate runtime on this tank

Estimated runtime

14.5 hours(0.6 days)

Fuel consumption ≈ 13.81 GPH at 75% load. Estimate based on industry-typical 1800 RPM standby curves (≈0.07 GPH/kW at full load). Actual consumption varies by engine, ambient temperature, fuel quality, and tuning.

Service intervals

Manufacturer-recommended intervals for the Blue Star VD230-01 under standby duty. Field intervals may differ based on load profile, ambient conditions, and fuel quality.

Oil & filter
Every 500 hours or 12 months
Coolant change
Every 6000 hours
Air filter
Every 1000 hours
Fuel filter
Every 500 hours
Major overhaul
≈ 20,000 hours
Load bank test
Every 12 months

Common failure modes

What we've seen fail on this platform. Use as a service-planning reference, not a diagnostic — actual failure modes depend heavily on duty cycle and maintenance history.

ComponentSymptomTypical hoursSeverity
Fuel quality / degradationHard starting, filter clogging, reduced power4,380+moderate
TurbochargerPower loss, excessive smoke under load12,000+moderate
BatteryFailed to start, slow crank8,760+minor

Frequently Asked Questions

What engine is in the VD230-01?
The Volvo Penta TAD851GE — a 7.7-liter inline-six turbocharged-aftercooled diesel rated 364 HP (272 kWm) at 1800 RPM. The TAD851GE is Volvo Penta's mid-range industrial diesel platform, sharing the same bore and stroke (4.33 x 5.31 in) as the smaller TAD572VE (5.13L I-4) but adding two cylinders. EPA Tier 3 certified for stationary emergency standby.
How does the VD230-01 compare to other Blue Star 200-250 kW diesels?
Blue Star offers three engine options at this kW class: the VD230-01 (Volvo Penta, 230 kW), the VD250-03 (Volvo Penta, 250 kW on the same TAD platform at a higher rating), and corresponding John Deere and Perkins models. The VD230-01 is the conservative choice — rated below the engine's peak capability, which provides greater thermal margin for continuous-duty standby applications.
What controller does the VD230-01 use?
The DSE DCP7310 — a newer controller platform compared to the Basler DGC-2020 used on Blue Star's earlier models. The DCP7310 features CAN bus J1939 communications, RS-485 interface, IP 65 front panel rating, and remote communications via DSE2548 annunciator. It is cULus Listed and NFPA 110 Level 1 compatible.
What alternator does the VD230-01 use?
A Stamford UCDI274J1 (at 480V) — a brushless, single-bearing, four-pole alternator with 125°C standby temperature rise and ±1% voltage regulation. Stamford alternators are widely deployed across the power generation industry, with parts and service available through Cummins Generator Technologies' global network.

Compatible equipment

Transfer switches

More in the Volvo Penta Diesel Standby

100–700 kW Volvo Penta diesel standby across Tier 4 Final, Tier 3, and Tier 2 — 22 models, one and three-phase.

View all 22models in this series →

Similar models

Blue Star Power Systems Blue Star VD250-03 250 kW liquid-cooled standby generator

Blue Star Power Systems

Blue Star VD250-03

Open Basler controller + Volvo Penta engine + Stamford alternator — no proprietary lock-in. Serviceable by any qualified tech, not just the dealer.

250 kW standby · Diesel · Liquid-cooled

250 kW Tier 3 diesel standby generator from Blue Star Power Systems. Volvo Penta TAD852GE 7.7L inline-six, DSE DCP7310 controller, 208-600V output.

Tier 33-phasecommerciallarge-commercial
Blue Star Power Systems Blue Star VD250-04FT4 250 kW liquid-cooled standby generator

Blue Star Power Systems

Blue Star VD250-04FT4

Open Basler controller + Volvo Penta engine + Stamford alternator — Tier 4 Final compliant, no proprietary lock-in. Serviceable by any qualified tech.

250 kW standby · Diesel · Liquid-cooled

250 kW Tier 4 Final diesel standby/prime generator from Blue Star Power Systems. Volvo Penta TAD1381VE 12.8L inline-six with SCR/DPF/DOC, DSE DCP7310 controller, 208-600V.

Tier 4 Final3-phasecommerciallarge-commercial
Blue Star Power Systems Blue Star VD250-04FT4MP 250 kW liquid-cooled standby generator
