Overview#
The Triton Power TP-JD50-T4F is a 50 kW diesel standby generator powered by the John Deere 3029HG530 turbocharged three-cylinder engine (2.9 L displacement) and paired with a Leroy Somer LSA 42.3 L9 alternator. This unit meets EPA Tier 4 Final emissions standards for nonroad applications via PowerTech EWX direct injection and DOC/DPF aftertreatment. The 92.5-gallon integral fuel tank with 125% fluid containment supports extended runtime without external fuel storage.
Available in both single-phase (40 kW standby at 120/240V) and three-phase (50 kW standby at 277/480V) configurations, the unit features a Deep Sea Electronics DSE7420 controller with comprehensive monitoring. Fuel consumption is rated at 11.2 L/hr (2.96 GPH) at full load.
Our service experience#
The John Deere 3029HG530 engine platform is widely supported through John Deere's dealer network, giving this Triton unit a servicing advantage in Northern California. At 50 kW standby, the TP-JD50-T4F serves the mid-range commercial market where units from Kohler, Generac, and Cummins typically dominate, but at a lower acquisition cost. The Tier 4 Final aftertreatment (DOC/DPF) adds maintenance complexity compared to Tier 2/3 units — periodic DPF regeneration monitoring is required — but delivers the emissions compliance needed for nonroad mobile applications.
